ASRock X570 Creator Motherboard Price Worldwide

By: ASRock

Model: X570 Creator

Sku: HWADYPGH84

$628.99

Availability: In Stock In Stock New

  • ASRock USB 3.2 Gen2: ASRock Front Panel Type C USB 3.2 Gen2 Header (10 Gb/s)
  • CPU: Supports AMD AM4 socket Ryzen 2000 and 3000 series processors*
  • Chipset: AMD X570
  • Memory: Dual Channel DDR4 Memory Technology
  • BIOS: 256Mb AMI UEFI Legal BIOS with GUI support
  • Graphics: Integrated AMD Radeon Vega Series Graphics in Ryzen Series APU*
  • Audio: 7.1 CH HD Audio with Content Protection (Realtek ALC1220 Audio Codec)
  • LAN1 x 10 Gigabit LAN 10/100/1000/2500/5000/10000 Mb/s (AQUANTIA AQC107):
  • Wireless LAN: Intel 802.11ax WiFi Module
  • SlotsAMD Ryzen series CPUs (Matisse)
  • Storage: 4 x SATA3 6.0 Gb/s Connectors, support RAID (RAID 0, RAID 1 and RAID 10), NCQ, AHCI and Hot Plug
  • Connector: 1 x DisplayPort 1.4 Input (DPIN2)
  • Rear Panel I/O: 2 x Antenna Ports
  • Support CD: Drivers, Utilities, AntiVirus Software (Trial Version), Google Chrome Browser and Toolbar
  • Hardware Monitor: Temperature Sensing: CPU, CPU/Water Pump, Chassis/Water Pump Fans
  • OS: Microsoft Windows 10 64-bit
Quantity :

Motherboard Built For Content Creators!

Built with primo components and out edge technology, ASRock Creator series makes content creation easy and pleasure.

Thunderbolt 3 Technology

Thunderbolt 3 technology brings speed and versatility to the most advanced USB Type-C, offering a fast and simple level of connection for work or home. It enables lightning-fast data transfer up to 40Gbps and connects up to 3 Thunderbolt 3 devices with a single wire, and even provides quick charging with 5V3A (15W).

AQUANTIA 10Gb/s BASE-T Ethernet

The new 10Gb/s network standard was specially designed to satisfy the user who is seeking immediate performance improvements. Based on AQUANTIA's AQtion client controller, it offers blazingly fast 10-gigabit/sec transfer speed over Cat6 cable. The 10Gb/s Ethernet not only fully compatible with 5Gb/s, 2.5Gb/s & Gigabit Lan but also delivers lightning fast transfer speed, perfect for media center, workstation and gaming PC.

ECC Memory Support

ECC (Error-correcting code) is a method of detecting and correcting single-bit memory errors. It's mission-critical to minimize errors in data especially for the server business and data centers. This motherboard is capable of supporting DDR4 ECC un-buffered memory modules that delivers server-grade performance and rock-solid durability for high-end computing systems, such as scientific or financial computers.

14 POWER PHASE DESIGN (IR DIGITAL PWM)

Featuring sturdy components and completely smooth power delivery to the CPU. Plus, it offers unmatched overclocking capabilities and enhanced performance with the lowest temperature for advanced gamers as well.

Dr. MOS

IR3555 Dr.MOS is the integrated power stage solution which is optimized for synchronous buck-set down voltage applications! Intelligently delivering higher current and driving up to 60A continuous current for each phase, thus providing improved thermal result and superior performance.

Wi-Fi 6 802.11ax

Welcome to the new Wi-Fi standard! ASRock's motherboard equipped with next generation Intel Wi-Fi 6 802.11ax adapter. The speed will be working up to 2.4Gbps and it will also natively operate with both 2.4Ghz and 5Ghz simultaneously. Significant improvement in bi-directional MU-MIMO support is another attractive feature as well.

STEEL SLOT WITH NEW-GEN PCI EXPRESS 4.0

The next generation PCI Express 4.0 is capable of performing twice the speed compared to previous 3rd generation. ASRock's exclusive Steel Slot with extra anchor points are revolutionary added to ensure signal stability and also making sure heavy graphics cards to be well-installed in the PCI-E slot safely.

Dual Hyper M.2 For SSD

Supports the next generation PCI Express 4.0 M.2 SSDs, it is capable of perform twice the speed compared to previous 3rd generation, giving a lightning fast data transferring experience.

RULE YOUR OWN LIGHTING WAY - POLYCHROME RGB

RULE YOUR OWN LIGHTING WAY - POLYCHROME RGB

In the Box

  • ASRock X570 Creator Motherboard
  • Quick Installation Guide, Support CD, I/O Shield
  • 4 x SATA Data Cables
  • ASRock SLI_HB_Bridge_2S Card
  • ASRock WiFi 2.4/5 GHz Antenna
  • Right Angle Mini DisplayPort to DisplayPort Cable
  • 2 x Screws for M.2 Sockets
  • 2 x Standoffs for M.2 Sockets
