Audio-Technica AT2022 X/Y Stereo Microphone
Audio-Technica AT2022 X/Y Stereo Microphone Display Gallery Item 1
Audio-Technica AT2022 X/Y Stereo Microphone - 2 Display Gallery Item 2
Audio-Technica AT2022 X/Y Stereo Microphone - 3 Display Gallery Item 3

Audio-Technica AT2022 X/Y Stereo Microphone - Shop Now and Save!

By: Audio-Technica

Model: AT2022

Sku: CNCVW5SPK1

Be the first to review this product

Sign up for price alert

Availability: Out of stock New

Availability: Out of stock

  • ELEMENTS: Fixed-charge back plate, permanently polarized condenser
  • POLAR PATTERN: X/Y Stereo
  • FREQUENCY RESPONSE: 20–20,000 Hz
  • LOW FREQUENCY ROLL-OFF: 150 Hz, 6 dB/octave
  • OPEN CIRCUIT SENSITIVITY: -41 dB (8.9 mV) re 1V at 1 Pa
  • CHANNEL BALANCE: 2.5 dB
  • IMPEDANCE: 200 ohms
  • MAXIMUM INPUT SOUND LEVEL: 122 dB SPL, 1 kHz at 1% T.H.D.
  • DYNAMIC RANGE (typical): 103 dB, 1 kHz at Max SPL
  • SIGNAL-TO-NOISE RATIO: 75 dB, 1 kHz at 1 Pa
  • BATTERY TYPE: 1.5V AA/UM3
  • SWITCH: off, on/flat, on/roll-off
  • OUTPUT CONNECTORIntegral 3-pin XLRM-type
Stock Request Notify When Available
  • Add to Wishlist
  • Add to Compare

The AT2022 is a condenser microphone designed for stereo recording. Two unidirectional condenser capsules in an X/Y configuration pivot to allow for narrow (90°) or wide (120°) stereo operation. The capsules also fold flat for storage and transportation. Designed for general stereo recording and field sound capture, the AT2022 provides the spatial impact and realism of a live sound field. The microphone comes equipped with a stand clamp, AA battery, fuzzy windscreen and .5 m cable that terminates in a 3.5 mm stereo plug.

In the Box

  • Audio-Technica AT2022 X/Y Stereo Microphone
  • AT8405a stand clamp for 5/8"-27 threaded stands
  • fuzzy windscreen
  • battery
  • soft protective pouch
