Close Focus Distance: 2.8 mm: 1.1 m (3.61 ft), 3.6 mm: 1.7 m (18.37 ft), 6 mm: 3.3 m (10.83 ft)
DORI Distance: Lens: 2.8 mm, 3.6 mm, 6 mm, Detect: 63.6 m (208.66 ft), 85.4 m (280.18 ft), 124.0 m (406.82 ft), Observe: 25.4 m (83.33 ft), 34.2 m (112.20 ft), 49.6 m (162.73 ft), Recognize: 12.7 m (41.67 ft), 17.1 m (56.10 ft), 24.8 m (81.36 ft), Identify: 6.4 m (21.00 ft), 8.5 m (27.89 ft), 12.4 m (40.68 ft), DORI (Detect, Observe, Recognize, Identify) is a standard system (EN-62676-4) for defining the ability of a person viewing the video to distinguish persons or objects within a covered area. The numbers in this table do not reflect intelligent function distances. For intelligent function distances, refer to installation and commissioning manual/project design tool.
Video
Video Compression: H.265; H.264; H.264H; H.264B; MJPEG (only supported by the sub stream)
Smart Codec: Smart H.265+, Smart H.264+
AI Coding: AI H.265, AI H.264
Video Frame Rate: Main stream: 2880 × 1620 @ (1–20) fps /, 2960 × 1668 @ (1–20) fps /, 2688 × 1520 @ (1–25/30 fps), Sub stream 1: 704 × 576 @ (1–25 fps)/, 704 × 480 @ (1–30 fps), Sub stream 2: 1920 × 1080 @ (1–25/30 fps), *The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity
