Discover Sony VPL-PHZ10 5,000 Lumens WUXGA Laser Light Source Projector

By: Sony

Model: VPL-PHZ10

Sku: 1W0YCNDIMC

Availability: Out of stock New

Availability: Out of stock

  • Display system: 3 LCD system
  • Display device: Size of effective display area: 0.76” (19.3 mm) x 3 BrightEra LCD Panel, Aspect ratio: 16:10, Number of pixels: 6,912,000 (1920 x 1200 x 3) pixels
  • Light source: Type: Laser diode
  • Filter cleaning / replacement cycle (Max.): 20,000 H (service maintenance)
  • Projection lens: Focus: Manual, Zoom - Powered/Manual: Manual, Zoom - Ratio: Approx. x 1.45, Throw ratio: 1.28:1 to 1.88:1, Lens shift - Powered/Manual: Manual, Lens shift - Range Vertical: +20% to +55%, Lens shift - Range Horizontal: +/- 10%
  • Screen size: 40" to 300" (1.02 m to 7.62 m)
  • Light output: Mode: Standard: 5,000 lm
  • Color light output: Mode: Standard: 5,000 lm
  • Contrast ratio (full white / full black): 500,000:1
  • Speaker: 16 W (monaural)
  • Displayable scanning frequency: Horizontal: 15 kHz to 92 kHz, Vertical: 48 Hz to 92 Hz
  • Display resolution: Computer signal input: Maximum display resolution: 1920 x 1200 dots, Video signal input: NTSC, PAL, SECAM, 480/60p, 576/50i, 720/60p, 720/50p, 1080/60i, 1080/50i, The following items are available for HDMI input only; 1080/60p, 1080/50p, 1080/24p
  • Color System: NTSC3.58, PAL, SECAM, NTSC4.43, PAL-M, PAL-N, PAL60
  • Keystone correction (Max.): Horizontal: +/- 30 degrees, Vertical: +/- 20 degrees
  • Operating temperature / Operating humidity: 0°to 40°C (32°F to 104°F) / 20 % to 80 % (no condensation)
  • Lamp Mode: Standard / Middle / Low: 36 dB / 28 dB / 25 dB
  • Storage temperature / Storage humidity: -10° to +60°C (14°F to 140°F) / 20 % to 80 % (no condensation)
  • Power requirements: AC 100 V to 240 V, 4.3 A to 1.7 A, 50 Hz / 60 Hz
  • Standby Mode / Networked Standby Mode Activated: Approx. 2 Minutes
Stock Request Notify When Available
  • Add to Wishlist
  • Add to Compare

The VPL-PHZ10 laser projector is a versatile, affordable choice for installation in a wide range of education, business and entertainment environments.

The powerful Z-Phosphor laser light source is teamed with Sony's advanced BrightEra 3LCD projection engine to deliver extremely bright, detail-packed WUXGA resolution images with generous 5000 lumens brightness and rich, stable colours. This laser light source allows up to 20,000 hours of virtually zero maintenance operation without the worry of sudden lamp failures. An automated filter system cuts the hassle of regular dust cleaning. Near-zero maintenance needs are complemented by a range of energy-saving features, significantly driving down total lifetime ownership costs. Constant Bright maintains consistent light output levels throughout the laser's 20,000 hours (at light output mode "Middle") recommended lifespan.

Offering a stylish blend-in design and low fan noise, the VPL-PHZ10 fits smoothly into almost any environment – from academic institutions to corporate environments. Mount the projector at any angle, even on its side or upside down. Set-up's easier than ever with a friendly new installation menu.

Very high image quality with Sony's advanced BrightEra 3LCD projection engine and Z-Phosphor laser light source

The Z-Phosphor laser light source is coupled with Sony's acclaimed BrightEra 3LCD projection engine to ensure high 5000 lumen image brightness with vivid, natural colour reproduction.

Advanced picture refinement technologies

Picture quality is boosted by advanced processing featured on Sony's home cinema projectors. Reality Creation uses a powerful pattern-matching database to optimise every pixel. Contrast Enhancer actively analyses and refines dark and light image areas for sparkling highlights and rich, deep blacks.

Hassle-free automatic filter cleaning

Focus on great-looking images instead of arduous maintenance tasks: new automated filter cleaning system removes dust every 100 hours.

Energy saving features

Reduce running costs even further with convenient energy-saving features: Picture Mute and Auto Dimming.

360° free-angle installation capability

Enjoy greater installation flexibility: position the projector freely at any angle – or its side or even upside down.

Quiet operation

Low fan noise ensures discreet, unobtrusive operation in quiet environments for academic and corporate use.

Picture Mode

Picture Mode ensures great-looking pictures in any presentation conditions. Select Standard, Dynamic, or Brightness Priority mode for optimised image quality, with any source and in every room.

Constant Brightness

Constant Bright maintains the same brightness of 4,500 lumens throughout the 14,000 hour recommended life span. When Constant Bright is on, and using 'Standard' light output mode

Crisp, detail-packed WUXGA resolution images

See fine detail in PC presentations, videos or multimedia signage with WUXGA (1920 x 1200) 16:10 resolution.

Up to 20,000 hours operation with virtually no maintenance

The advanced laser light source offers up to 20,000 hours operation without lamp exchange, reducing lifetime running costs compared with traditional projectors.

Save time with every presentation

Quick power On/Off dramatically cuts warm-up time after switch-on before you can start presenting at full brightness.

Supports HDBaseT

Simpler, more cost-effective installation and connectivity with digital transmission of HD video, audio and networking/control over a single Ethernet cable.

Slim, attractive blend-in design

The slim, stylish case design features a flat top surface that blends in discreetly when the projector is ceiling mounted.

Simple set-up with friendly new Installation menu

Easily adjust projector settings with remote commander.

In the Box

  • Sony VPL-PHZ10 5,000 Lumens WUXGA Laser Light Source Projector
  • Remote
