TRENDnet 240 W Single Output Industrial DIN-Rail Power Supply
TRENDnet 240 W Single Output Industrial DIN-Rail Power Supply Display Gallery Item 1
TRENDnet 240 W Single Output Industrial DIN-Rail Power Supply - 2 Display Gallery Item 2
TRENDnet 240 W Single Output Industrial DIN-Rail Power Supply - 3 Display Gallery Item 3
TRENDnet 240 W Single Output Industrial DIN-Rail Power Supply - 4 Display Gallery Item 4
TRENDnet 240 W Single Output Industrial DIN-Rail Power Supply - 5 Display Gallery Item 5

Discover TRENDnet 240 W Single Output Industrial DIN-Rail Power Supply

By: TRENDnet

Model: TI-S24048

Sku: FCNW8PAL8T

Be the first to review this product

Sign up for price alert

$219.99

Availability: In Stock In Stock

New

  • Interface: Input: 100-240 V AC, 50/60 Hz, 1.8 A 125-370 V DC, Output: 240 Watts, 48 V, 5 A, DIN-rail: TS-35/7.5 or 15
  • Housing: Metal case, DIN-rail mount, LED indicator confirms power to the unit
  • Special Features: DC OK relay contact, 150% peak load capacity, Short circuit/overload/over voltage/over temperature protection, Protection type: shut down and repower
  • Operating Temperature: - 25 to 70 °C (- 13 to 158 °F), Max. 95 % non-condensing
  • MTBF: 1,693,000 hours
  • Certifications (Mean Well) : CE, UL 508CB 60950-1, TUV EN60950-1
Quantity:
  • Add to Wishlist
  • Add to Compare
  • Industrial power supply with integrated DIN-rail mount
  • Provides up to 240 Watts of power (48 V, 5 A)
  • Built-in active PFC (PF 0.93)
  • Short circuit/overload/over voltage/over temperature protection
  • High efficiency (94%) design
  • UL 508 approved
  • 100 % full load burn-in test
  • Extreme -25 to 70 °C (-13 to 158 °F) operating temperature range
  • NDAA / TAA compliant

TRENDnet's high efficiency 240 W Single Output Industrial DIN-Rail Power Supply, model TI-S24048 (Mean Well SDR-240-48), supplies up to 240 Watts (48 V, 5 A) of power to industrial PoE equipment such as switches, network cameras, and WiFi access points. This power supply comes with active PFC, an integrated DIN-rail mount, and overload current protection.

240Watt

Provides up to 240 Watts (48 V, 5 A) of power for PoE devices such as switches, network cameras, and access points

Active PFC

The built-in active Power Factor Controller (PFC, PF>0.93) helps eliminate unusable reactive power

Overload Protection

Overload/short circuit/over voltage/over temperature protection

Full Load Test

This power supply undergoes a 100 % full load burn-in test

Passive Cooling

Cooling by free air convection

DIN-Rail Mount

Compliance to EN55011, EN55022 (CISPR22), EN61204-3 Class B, EN61000-3-2/3, EN61000-4-2, 3, 4, 5, 6, 8, 11, EN55024, EN61000-6-2, EN61204-3, heavy industry level, criteria A, SEMI F47, and GL approved

Vibration Resistant

Rated for vibration (IEC 60068-2-6)

LED Indicator

LED indicator confirms power to the unit

In the Box

  • TRENDnet 240 W Single Output Industrial DIN-Rail Power Supply
